MikroTik RouterBOARD QRT-2 2 GHz 17dBi Flat Panel Antenna with Integrated Radio
The MikroTik RouterBOARD QRT-2 is a durable outdoor flat panel antenna that comes with a built-in RouterBOARD. It features a 17dBi antenna and an exceptionally powerful 2GHz wireless transmitter. The QRT-2 houses a state-of-the-art dual chain wireless device with a high-performance, high-output power wireless transmitter, as well as a Gigabit Ethernet port for optimal use of 802.11n high-speed wireless technology. With its user-friendly design and fast deployment capabilities, the QRT-2 is perfect for point-to-point connections.
Tech Specs
| Device Specifications | |
|---|---|
| General | |
| Product code | RBQRTG-2SHPnD |
| Suggested price | $149.00 |
| Architecture | MIPSBE |
| CPU | AR9342 |
| CPU core count | 1 |
| CPU nominal frequency | 600 MHz |
| Dimensions | 309 x 230 x 50 mm |
| RouterOS license | 4 |
| Operating System | RouterOS |
| Size of RAM | 64 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| MTBF | Approximately 200'000 hours at 25°C |
| Tested ambient temperature | -40°C to 70°C |
| Powering | |
| Number of DC inputs | 1 (PoE-IN) |
| Max power consumption | 11 W |
| PoE in | Passive PoE |
| Cooling type | Passive |
| PoE in input Voltage | 13-30 V |
| Wireless Specifications | |
| Max data rate (2.4 GHz) | 300 Mbit/s |
| Number of chains | 2 |
| Standards | 802.11b/g/n |
| Antenna gain (dBi) | 17 |
| Chip model | AR9342 |
| Generation | Wi-Fi 4 |
| Ethernet | |
| 10/100/1000 Ethernet ports | 1 |
| Other | |
| PCB temperature monitor | Yes |
| Voltage monitor | Yes |
| Beeper | Yes |
| Certification | CE, FCC, IC, EAC, ROHS |
FAQs
Q1: What is MikroTik RBQRTG‑2SHPnD and what is it used for?
A: The RBQRTG‑2SHPnD is an outdoor flat‑panel antenna with a built‑in RouterBOARD. It’s designed for long‑range point‑to‑point (PtP) or point‑to‑multipoint (PtMP) wireless links in the 2.4 GHz band.
Q2: What are the hardware and wireless specifications of this device?
A: It uses an Atheros AR9342 CPU (600 MHz), has 64 MB RAM and 16 MB flash, supports dual‑chain 802.11b/g/n on 2.4 GHz, and offers up to 300 Mbps wireless data rate (2×2 MIMO) with its integrated 17 dBi antenna.
Q3: What kind of network and power connectivity does RBQRTG‑2SHPnD support?
A: It includes one Gigabit Ethernet port for wired connectivity. It is powered via passive PoE‑in (13–30 V DC) and consumes up to about 11 W. Cooling is passive, suitable for outdoor use.
Q4: What environmental conditions and build quality does the device support?
A: The unit is built for outdoor deployment, with an operating temperature range from –40 °C to +70 °C, making it suitable for a variety of climates and harsh weather conditions.
Q5: What networking use cases is RBQRTG‑2SHPnD best suited for?
A: It’s ideal for building long‑range wireless links (backbone, bridging, PtP), extending networks over distances where wired cabling is impractical, or providing connectivity in rural / remote locations.
