Teltonika RUTM55 – Industrial 5G Router with Dual SIM and Serial Connectivity
The Teltonika RUTM55 is an industrial-grade 5G router designed to deliver ultra-high-speed cellular connectivity alongside versatile wired and wireless interfaces. Supporting 5G speeds of up to 3.4 Gbps, it provides reliable, low-latency connectivity for demanding industrial networks, making it suitable for automation, remote monitoring, and critical infrastructure deployments.
Equipped with four Gigabit Ethernet ports and integrated WiFi 5, the RUTM55 offers flexible network connectivity for both modern and legacy environments. Dual SIM and eSIM support with automatic failover ensures maximum uptime, enabling seamless switching between mobile networks for backup WAN and resilience. Integrated RS232 and RS485 serial interfaces allow direct connection of legacy industrial equipment, helping protect existing investments while modernising network infrastructure.
Designed specifically for industrial use, the RUTM55 features a robust 3-pin power input and multiple digital inputs and outputs for system integration. This combination of high-speed 5G performance, redundancy, and industrial-ready design makes the Teltonika RUTM55 a future-proof solution for reliable connectivity in harsh and mission-critical environments.
Tech Specs
View the full Teltonika RUTM55 datasheet here.
| Device Specifications | |
|---|---|
| Ethernet | (4) RJ45 ports, 10/100/1000 Mbps |
| I/O | (1) Digital dry input (1) Digital galvanically isolated input (1) Analog input (1) Isolated open collector output (1) SPST relay output |
| Status LEDs | (3) Mobile connection type (3) Mobile connection strength (6) LAN status (1) Power |
| SIM | (2) Mini SIM (2FF) slots 1.8 V / 3 V Internal SIM holders |
| Antennas | (4) SMA for Mobile (2) RP-SMA for WiFi (1) SMA for GNSS |
| USB | (1) USB Type-A port for external devices |
| RS232 | (2) pins in 16-pin terminal block |
| RS485 | (2) pins in 16-pin terminal block |
| Reset | Reboot / User default reset / Factory reset button |
| Power Connector | (1) 3-pin power connector |
| Casing Material | Anodised aluminium housing and panels |
| Dimensions (W x H x D) | 132 x 44.2 x 95 mm |
| Weight | 430 g |
| Mounting Options | DIN rail Wall mount Flat surface (Additional kit required) |
| Operating Temperature | -40°C to 75°C |
| Operating Humidity | 10% to 90% non-condensing |
| Ingress Protection Rating | IP30 |
