MikroTik hEX S 5 Port Gigabit Router
Please contact us for stocking information.
MikroTik's hEX-S is a compact and affordable 5-port gigabit router with a dual-core 880 MHz CPU and 256 MB of RAM. It can be powered via mains or PoE, and also supports hardware encryption and The Dude server package.
Tech Specs
| Device Specifications | |
|---|---|
| Product code | RB760iGS |
| Architecture | MMIPS |
| CPU | MT7621A |
| CPU core count | 2 |
| CPU Threads count | 4 |
| Switch chip model | MT7621A |
| Dimensions | 113 x 89 x 28 mm |
| RouterOS license | 4 |
| Operating System | RouterOS |
| Size of RAM | 256 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| MTBF | Approximately 100'000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
| IPsec hardware acceleration | Yes |
| Suggested price | $79.00 |
| Powering | |
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 12-57 V |
| Max power consumption | 24 W |
| Max power consumption without attachments | 6 W |
| PoE in | 802.3af/at |
| Cooling type | Passive |
| PoE in input Voltage | 12-57 V |
| PoE-out | |
| PoE-out ports | Ether5 |
| PoE out | Passive PoE up to 57V |
| Low voltage PoE-Out current limit | 500 mA |
| High voltage PoE-Out current limit | 500 mA |
| Max total out (A) | 500 mA |
| Ethernet | |
| 10/100/1000 Ethernet ports | 5 |
| Fiber | |
| SFP ports | 1 |
| Peripherals | |
| Memory card type | microSD |
| Memory Cards | 1 |
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | USB type A |
| Max USB current (A) | 1 |
| Other | |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
| Mode button | Yes |
| Beeper | Yes |
| Certification & Approvals | |
| Certification | CE, EAC, ROHS |
| IP | IP20 |
FAQs
Q: What is the MikroTik RB760iGS used for?
A: The RB760iGS is a compact wired router designed for high‑speed networks where wireless is not required, offering five Gigabit Ethernet ports, one SFP port and PoE‑out capability on the last LAN port.
Q: What are the key hardware specifications of the RB760iGS?
A: It features a dual‑core 880 MHz CPU, 256 MB RAM, 16 MB flash, five 10/100/1000 Mbps Ethernet ports, and one 1.25 Gbps SFP cage, providing advanced routing capabilities in a small form factor.
Q: What power and PoE‑in/out features does the RB760iGS support?
A: It supports DC jack input (12 – 57 V) or 802.3af/at PoE‑in, and provides passive PoE‑out on port 5 (up to 57 V at 500 mA), making it suitable for powering a downstream device over Ethernet.
Q: In what network scenarios is the RB760iGS most suitable?
A: It is ideal for wired network setups in homes, branches or offices; perfect when you need full Gigabit wired performance and SFP fibre uplink but don’t require built‑in WiFi.
Q: What are the installation and operating condition considerations for the RB760iGS?
A: Designed for indoor use, it supports operating temperatures from ‑40 °C to +70 °C, in a compact chassis (113 × 89 × 28 mm), making it easy to place on a desktop or mounting shelf.
