MikroTik RouterBOARD Cloud Core Router CCR2004-1G-12S+2XS
Please contact us for stocking information.
The MikroTik CCR2004-1G-12S+2XS router has incredibly powerful performance with 12 x 10G SFP+ and 2 x 25G SFP28 ports, making it a great addition to any professional networking arsenal. It offers impressive results for single tunnel and BGP feed processing, and can handle 10G, 40G, and 25G connections. With dual redundant power supply, downtime is not a concern. Pair it with other MikroTik multiport products for even more networking capabilities.
Tech Specs
| Device Specifications | |
|---|---|
| Specifications | |
| Product code | CCR2004-1G-12S+2XS |
| Architecture | ARM 64bit |
| CPU | AL32400 |
| CPU core count | 4 |
| CPU nominal frequency | 1700 MHz |
| Dimensions | 443 x 224 x 44 mm |
| RouterOS license | 6 |
| Operating System | RouterOS v7 |
| Size of RAM | 4 GB |
| Storage size | 128 MB |
| Storage type | NAND |
| MTBF | Approximately 200'000 hours at 25°C |
| Tested ambient temperature | -20°C to 60°C |
| IPsec hardware acceleration | Yes |
| Suggested price | $595.00 |
| Powering | |
| Number of AC inputs | 2 |
| AC input range | 100-240 |
| Max power consumption | 60 W |
| Max power consumption without attachments | 31 W |
| Cooling type | 2 fans |
| Ethernet | |
| 10/100/1000 Ethernet ports | 1 |
| Fiber | |
| SFP+ ports | 12 |
| Number of 25G SFP28 ports | 2 |
| Peripherals | |
| Serial console port | RJ45 |
| Other | |
| CPU temperature monitor | Yes |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
| Certification & Approvals | |
| Certification | CE, EAC, ROHS |
| IP | IP20 |
FAQs
Q: What is the MikroTik CCR2004‑1G‑12S+2XS used for?
A: This router is designed for high‑density aggregation and backbone deployments, offering extensive SFP+ and SFP28 port density for 10 Gbps and 25 Gbps links, and suited for core networks, carriers or data centres.
Q: What are the key hardware specifications of the CCR2004‑1G‑12S+2XS?
A: It features a quad‑core ARMv8 CPU at 1.7 GHz, 4 GB RAM, 128 MB NAND storage, 12 × 10 Gb SFP+ ports, 2 × 25 Gb SFP28 ports, 1 × 1 Gb RJ‑45 ETH port, dual AC input power supplies, and supports RouterOS v7 Licence Level 6.
Q: What power and performance features does the router support?
A: It supports dual AC (100–240 V) redundant power supplies, consumes up to around 60 W under full load, includes active fan cooling, and offers hardware‑accelerated IPsec and high throughput across its ports.
Q: What networking features and connectivity options does the CCR2004‑1G‑12S+2XS provide?
A: With its 12 10 Gb SFP+ and 2 25 Gb SFP28 ports, it supports high‑speed uplinks and segmentation for enterprise networks. The included 1 Gb RJ‑45 port allows management or legacy connections, and RouterOS provides advanced routing, VPN, BGP and firewall capabilities.
Q: In what deployment scenarios is the CCR2004‑1G‑12S+2XS ideal and what should be considered for installation?
A: It is ideal for rack‑mounted installation in data centres, carrier POPs or large enterprise cores that require large port density and high‑speed interconnects. Installation should ensure adequate cooling, rack space (1 U), cable management for SFP/SFP28 modules and redundancy in power for high availability.
