Teltonika Altos Wi-Fi 7 Router for 5G Fixed Wireless Access
Please contact us for stocking information.
The Teltonika CAP700 Altos is a high-performance 5G fixed wireless access router that combines next-generation Wi-Fi 7 connectivity with ultra-fast mobile broadband. Designed to deliver reliable high-speed internet where wired infrastructure is limited or unavailable, it supports modern wireless performance across multiple bands while providing low latency and improved network efficiency.
Built for demanding environments, the CAP700 Altos enables fast, stable connectivity for small businesses, branch sites, temporary installations, and rural locations. Its 5G connectivity provides high-throughput WAN access, while Wi-Fi 7 enhances local network capacity to support bandwidth-intensive applications such as cloud services, video conferencing, remote monitoring, and high-resolution media streaming.
With advanced routing capabilities and support for secure remote management, the CAP700 Altos integrates easily into managed network deployments. It offers a dependable solution for organisations seeking resilient primary connectivity or automatic failover, as well as for home users requiring enterprise-grade wireless performance and future-ready mobile broadband access.
Tech Specs
View the Teltonika RUTC50 datasheet here.
| Device Specifications | |
|---|---|
| Mobile | |
| Mobile Module | 5G NR up to 4.0 Gbps DL / 900 Mbps UL 4G LTE (Cat 19) up to 1.6 Gbps DL / 200 Mbps UL 3G – 42 Mbps DL / 5.76 Mbps UL |
| 3GPP Release | Release 17 |
| Status Monitoring | IMSI, ICCID, operator state, network type, bandwidth, signal metrics (RSSI, SINR, RSRP, RSRQ, EC/IO, RSCP), data usage, cell & band data, MCC & MNC |
| SMS | SMS status & configuration Email ↔ SMS, HTTP, SMS forwarding Scheduled SMS, autoreply, SMPP |
| USSD | Send & receive USSD messages |
| Operator Control | Block/allow lists by country or operator |
| Band Management | Band lock & band usage display |
| SIM Management | SIM PIN control & Auto APN |
| Bridge / Passthrough | Direct ISP bridge mode WAN IP passthrough to LAN device |
| Wireless | |
| Wireless Mode | 802.11a/b/g/n/ac/ax/be (Wi-Fi 7) Dual Band, 2x2 MIMO Access Point mode |
| Wi-Fi Security | WPA-PSK, WPA2-PSK, WPA3-SAE WPA/WPA2/WPA3-EAP, OWE CCMP & TKIP ciphers |
| Wi-Fi Users | Up to 128 simultaneous connections |
| QR Code Access | Scan to join Wi-Fi automatically without entering credentials |
| Ethernet | |
| WAN Ports | 1 × 10/100/1000 Mbps |
| LAN Ports | 3 × 10/100/1000 Mbps |
| Port Modes | WAN, LAN, configurable |
| DHCP | Server, client, relay Static & dynamic IP allocation |
| VLAN | 802.1Q VLAN tagging VLAN separation & priority tagging |
| Load Balancing | Multi-WAN load balancing Failover & traffic distribution |
| QoS | Traffic prioritization & bandwidth control |
| Routing | Static routing Dynamic routing support |
| NAT | Port forwarding NAT & NAT helpers |
| Firewall | Stateful firewall Port & traffic filtering Attack prevention & access control |
| Security & VPN | |
| VPN Types | IPsec L2TP PPTP OpenVPN |
| VPN Modes | Client & server support Site-to-site & remote access |
| Encryption | DES, 3DES, AES SHA-1 & SHA-2 authentication |
| Authentication | Pre-shared keys Certificates User authentication |
| Firewall Security | Stateful packet inspection DoS/DDoS protection Intrusion prevention |
| Access Control | IP & MAC filtering User-based access policies |
| Management & Monitoring | |
| WEB UI | HTTP/HTTPS interface Configuration, status, logs, firmware updates |
| FOTA | Firmware update over server Automatic notification |
| SSH / CLI | SSH v1/v2 access for configuration and diagnostics |
| RMS | Remote Management System support |
| IoT Platforms | ThingWorx, Cumulocity, Azure IoT Hub, AWS IoT Core |
| APIs | Teltonika Web API (beta) JSON-RPC over HTTP/HTTPS MQTT Publisher/Broker |
| Monitoring | Network traffic charts Real-time signal monitoring Event logs & alerting |
| System & Physical Specs | |
| CPU | Qualcomm |
| RAM | 1 GB LPDDR4 |
| Storage | 8 GB eMMC |
| Operating System | RutOS (OpenWrt based) |
| Dimensions | Ø 100 mm × 185 mm |
| Weight | 720 g |
| Mounting | Flat surface placement |
| Operating Temperature | 0 °C to 45 °C |
| Operating Humidity | 5% to 95% non-condensing |
| Ingress Protection | IP30 |
| Regulatory Certifications | CE, UKCA, EAC, UCRF, RCM, CB, WEEE EMC: EN 55032, EN 55035, EN 301489, etc. RF: EN 300 328, EN 301 893, EN 301 908 series Safety: EN IEC 62368-1, AS/NZS 62368.1, UL 62368-1 |
FAQs
Q1: What is the Teltonika CAP700 Altos and what is it used for?
A: The Teltonika CAP700 Altos is a high‑performance 5G router with Wi‑Fi 7 designed for Fixed Wireless Access (FWA). It delivers ultra‑fast mobile broadband to homes, offices, and remote locations where traditional wired internet is unavailable or costly.
Q2: What cellular and wireless technologies does the Altos support?
A: The Altos supports 5G NR for ultra‑fast mobile broadband with speeds up to several gigabits downlink and uplink, and also works with 4G LTE and 3G networks for broad compatibility. It features dual‑band Wi‑Fi 7 (802.11be) to provide next‑generation wireless speeds and capacity.
Q3: How does the Altos handle wired networking and device connections?
A: The router includes multiple Ethernet ports, including a 2.5 Gbps WAN/LAN port and a 1 Gbps LAN port, allowing high‑speed wired connections to switches, computers, and local servers. This lets users benefit from multi‑gigabit broadband both wirelessly and wired.
Q4: What advanced networking and management features are available?
A: The Altos runs on Teltonika RutOS, a full‑featured operating system that includes robust routing, firewall, VPN support, and advanced security. It integrates with Teltonika’s Remote Management System (RMS) for zero‑touch deployment, remote configuration, monitoring, and maintenance.
Q5: What physical and deployment features does the Altos offer?
A: Built with internal cellular and Wi‑Fi antennas, the Altos has a compact design suitable for indoor installation. It supports SIM‑based mobile broadband, easy setup, and features that make it ideal for homes, small businesses, and managed FWA deployments where high performance and reliability are essential.
