Ubiquiti UniFi Protect Floodlight
Illuminate your surroundings with a powerful, motion-activated light. Emitting 550 lumens of bright LED light, this weatherproof floodlight can be easily wall-mounted and powered through PoE. With its built-in motion detection technology, you can rest easy knowing your outdoor space is protected and well-lit.
Tech Specs
| Device Specifications | |
|---|---|
| Mechanical | |
| Dimensions | 135 x 65 x 50 mm (5.3 x 2.6 x 2") |
| Weight | Without mount: 216 g (7.6 oz) With flat wall mount: 236 g (8.3 oz) With angle mount: 273 g (9.6 oz) |
| Enclosure Material | Polycarbonate, aluminum alloy |
| Mount Material | Angle Mount: Polycarbonate Flat Wall Mount: Polycarbonate |
| Weatherproofing | IPX5 |
| Hardware | |
| Networking Interface | 10/100 MbE RJ45 port |
| Power Method | PoE, 48V DC, 0.22A Max. |
| Max. Power Consumption | 12.95W |
| ESD/EMP Protection | Air: ± 8kV, contact: ± 8kV |
| Radio Frequency | Bluetooth 4.0 |
| LEDs | R/B/W |
| Buttons | (1) Factory-reset |
| Ambient Operating Temperature | -10 to 45° C (14 to 113° F) |
| Ambient Operating Humidity | 20 to 80% noncondensing |
| Certifications | FCC, IC, CE |
| Software | |
| Application Requirements | Web Application UniFi Protect |
| Mobile App | UniFi Protect iOS™ and Android™ |
FAQs
Q: What is the Ubiquiti UP-Floodlight and how does it integrate with UniFi?
A: The UP-Floodlight is a PoE-powered smart LED floodlight featuring integrated motion and light sensors. It pairs with UniFi Protect for remote control and automation.
Q: How bright is the UP-Floodlight and how far can it detect motion?
A: It delivers 550 lumens of LED light and can detect motion from up to 5 meters away.
Q: What power options does the UP-Floodlight offer and what’s its power consumption?
A: This device uses 802.3af PoE (48 V DC, 0.22 A max) and consumes approximately 10.5 – 12.95 W depending on configuration.
Q: What are the physical and environmental specifications?
A: Compact at 135 × 65 × 50 mm, it weighs 216 g (without mount, 273 g with angle mount). Housed in durable polycarbonate and metal, it’s rated IPX5 for water resistance.
Q: What installation elements are included and how is it configured?
A: Includes both a flat-wall mount and angle mount with a screw kit for flexible placement. Setup and management are handled entirely via the UniFi Protect app (web and mobile).
