Ubiquiti UISP Cable Pro
The Ubiquiti UISP-Cable-Pro is an expertly designed Category 5e cable, featuring a durable jacket that provides excellent insulation and protects against extreme weather conditions like rain and snow. In addition, its internal foil shielding and drain wire protect against electrostatic discharge (ESD) and maintain high Gigabit Ethernet link rates even with electromagnetic interference present.
Tech Specs
| Device Specifications | |
|---|---|
| Box dimensions | 330 x 330 x 340 mm (13 x 13 x 13.4") |
| Box weight | 12 kg (26.5 lb) |
| Cable length | 305 m (1,000 ft) |
| Cable color | Black |
| Cable type | CAT5e, shielded |
| UV resistance | ASTM G 151/154 |
| Ethernet support | Up to 1 Gbps |
| Conductor wire gauge | 24 AWG |
| Conductor | Solid bare copper |
| Conductor diameter | 0.500 ± 0.005 mm |
| Insulation type | Solid polyethylene |
| Insulation thickness | Avg. 0.26 mm Min. 0.25 mm |
| Insulation diameter | 1.04 ± 0.03 mm |
| Separation (Polyester wrapping) | Thick: 0.025 mm Extent: 20 mm |
| Anti-crosstalk divider | None |
| Cable shield (Aluminum foil) | Thick: 0.060 mm Extent: 18 mm |
| ESD drain wire | 0.4 CCS |
| Rip cord | Yes |
| Jacket material | Polyethylene |
| Jacket thickness | Avg. 0.50 mm Min. 0.46 mm |
| Jacket outer diameter | 6.0 ± 0.30 mm |
| Jacket color | Black |
| Storage temperature | -30 to 75° C (-22 to 167° F) |
| Installation temperature | -20 to 60° C (-4 to 140° F) |
| Ambient operating temperature | -40 to 80° C (-40 to 176° F) |
| Standards | ANSI/TIA-568-C.2 (2009) ISO/IEC 11801 (Edition 2.2) |
| NDAA Compliant | Yes |
FAQs
Q: What is the Ubiquiti UISP-Cable-Pro used for?
A: The UISP-Cable-Pro is a shielded Ethernet cable designed for professional outdoor network deployments, providing reliable data and PoE transmission for UISP devices.
Q: Is the UISP-Cable-Pro suitable for outdoor installations?
A: Yes, it features a weather-resistant and UV-protected jacket, making it ideal for outdoor use in harsh environmental conditions.
Q: Can the UISP-Cable-Pro support PoE devices?
A: Yes, it supports PoE and PoE+ delivery, allowing both power and data to be transmitted over a single cable to compatible devices.
Q: What type of shielding does the UISP-Cable-Pro provide?
A: The cable includes full shielding to reduce electromagnetic interference (EMI), ensuring stable performance for sensitive network applications.
Q: Which devices are compatible with the UISP-Cable-Pro?
A: It is compatible with Ubiquiti UISP devices, including access points, switches, and routers, as well as other Ethernet-based PoE devices.
