Ubiquiti UniFi G3 Reader Pro
The Ubiquiti G3 Reader Pro combines advanced access control with integrated video and intercom functionality for enhanced security and communication. Supporting NFC cards, PINs, Apple Touch Pass, face unlock, and the UniFi Identity mobile app, it offers versatile unlocking options. The built-in doorbell and two-way video intercom ensure clear visitor visuals and interaction, making it ideal for modern visitor management.
Designed for both indoor and outdoor use, the G3 Reader Pro is IP55-rated for weather resistance and performs reliably in temperatures from -10 to 45°C. Its video functionality supports ADA-compliant mounting heights, ensuring accessibility for all users. With PoE connectivity, it integrates seamlessly with the UniFi Access Hub, simplifying installation and delivering a complete access control solution for any environment.
Tech Specs
Click here to see the Ubiquiti UniFi G3 Reader Pro datasheet
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 160 x 40.4 x 40.55 mm (6.3 x 1.59 x 1.6") |
| Integrated Camera | ✓ |
| NFC Card & Keyfob Access | ✓ |
| PIN Access | ✓ |
| Apple/Google Wallet | ✓ |
| Mobile Unlock | ✓ |
| Two-Way Intercom & Doorbell Access | ✓ |
| NDAA Compliant | ✓ |
| UL 294 Level | Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| Weatherproofing | IP55 |
| Mechanical | |
| Weight | 136 g (4.8 oz) |
| Enclosure Material | Polycarbonate, glass |
| Mount Material | Aluminum alloy |
| Mounting | Wall, gang-box mount (Included) Angle mount, junction box (Optional) |
| Hardware | |
| Indoor and Outdoor Use | Yes |
| Ambient Operating Temperature | Device: -30 to 45° C (-22 to 113° F) Display: -10 to 45° C (14 to 113° F) |
| Ambient Operating Humidity | 5 to 90% noncondensing |
| Networking Interface | (1) GbE RJ45 port |
| Connectivity | BLE 4.2 NFC |
| Power Method | PoE UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU |
| Max. Power Consumption | 6W |
| Supported Voltage Range | 48V DC |
| ESD/EMP Protection | Air: ±15kV, contact: ±8kV |
| Sensors | Proximity sensor |
| Display | |
| Screen Size | 120 mm (4.7") diagonal |
| Touch Screen Technology | Capacitive touch |
| Display Luminance | 480 nits (Typical) |
| Screen Orientation | Portrait |
| Resolution | 1280 x 286 px |
| Microphone | ✓ |
| Speaker | ✓ |
| LEDs & Buttons | |
| LEDs | R/G/B/W/Amber |
| Button | (1) Factory-reset |
| NFC | |
| Frequency | 13.56 MHz |
| Read Range | < 30 mm (1.18") |
| Technology | ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T and T5T ECP 2.0 |
| PoE & UL | |
| PoE Cabling Requirements | Cat 5e cabling minimum Conductor gauge: 26 AWG for patch cords; 24 AWG for horizontal/riser cable |
| UL 294 Statement | Compliance with IEEE 802.3 specifications was not verified as part of UL 294. Intended to comply with NEC ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and 3 Circuits |
| CAN/ULC-60839-11-1 Grade | Grade assignment: I |
| Certifications | CE, FCC, IC, SRRC, UL 294, CAN/ULC-60839-11-1 |
| Document Number & Revision | UA-G3-Pro-W / UA-G3-Pro-B, V01 |
| Software | |
| Management Application | Access |
| Software Information | The software version can be checked at https://unifi.ui.com |
FAQs
Q. What type of device is the Ubiquiti UA-G3-Pro?
A: The UA-G3-Pro is an RFID keyfob designed for use with UniFi Access readers, providing secure and convenient contactless entry.
Q. What technology does the UA-G3-Pro use for authentication?
A: The UA-G3-Pro uses RFID technology to enable fast and secure authentication with compatible UniFi Access readers.
Q. How does the UA-G3-Pro integrate with UniFi Access?
A: The keyfob pairs with UniFi Access readers, allowing centralised management, real-time monitoring, and event logging through the UniFi Access platform.
Q. What durability and environmental features does the UA-G3-Pro offer?
A: The UA-G3-Pro is built for everyday use, lightweight, portable, and resistant to wear, making it suitable for long-term deployment.
Q. Can multiple UA-G3-Pro keyfobs be managed together?
A: Yes, multiple UA-G3-Pro keyfobs can be registered and managed within UniFi Access, enabling scalable user and access control across a facility.
