Ubiquiti UniFi Gate Hub
UniFi Gate Hub – Smart Access Controller for Automated Gate Management
The UniFi Gate Hub is an advanced controller designed to manage automated gates and secure entry points with seamless integration into UniFi Access and UniFi Protect systems. It enables smart, centralised gate access control through connected readers or intercoms.
Equipped with two gate operator terminals (dry) and a 12V lock terminal for side doors, it also includes an AUX terminal for an external siren and five additional sensor or emergency inputs. When paired with a UniFi AI Camera, the Gate Hub supports automatic license plate recognition for convenient, secure vehicle access.
Powered by PoE++, the Gate Hub connects up to four UniFi Access readers or UniFi Protect cameras, offering flexible deployment for commercial, residential, or gated community installations.
Tech Specs
Click here to view the Ubiquiti UniFi Gate Hub datasheet.
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 175 x 126 x 26 mm (6.9 x 5 x 1") |
| UniFi Application Suite | Access ✓ |
| Supported Doors | 1 gate, 1 side door |
| Maximum User Count | 6,000 |
| Input Terminals | (1) Gate exit request (1) Gate position (1) Side door exit request (1) Side door position (1) Emergency |
| Power Method | PoE++ UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU |
| NDAA Compliant | ✓ |
| UL 294 Level | Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| Mechanical | |
| Weight | 460 g (1 lb) |
| Enclosure Material | Polycarbonate |
| Mounting | DIN-rail (Included) |
| Hardware | |
| Digital Input | Gate exit request, gate position, side door exit request, side door position, emergency |
| Dry Output Relay | (2) Operator: rated 30V DC, up to 1A (1) Aux: rated 30V DC, up to 1A |
| Powered Output Relay | Side door lock: 12V DC, up to 1A |
| Indoor and Outdoor Use | Indoor only: device itself Outdoor: with waterproof junction box |
| Ambient Operating Temperature | -30 to 60° C (-22 to 140° F) |
| Ambient Operating Humidity | 5 to 90% noncondensing |
| Networking Interface | (5) 10/100/1000 Base-T |
| PoE Interface | (1) PoE++ input, 50V DC, 1A (4) PoE+ outputs, 50V DC, 30W per port (Max 55W aggregated) |
| Max. Power Consumption | 22W (Without PoE output) 60W (With PoE output) |
| LEDs | W/B Learn More |
| Buttons | (1) Factory-reset< |
FAQs
Q: What is the Ubiquiti UA-Hub-Gate used for?
A: The UA-Hub-Gate is a smart network gateway and hub that connects and manages multiple devices, enabling automation and centralised control in UniFi or smart home networks.
Q: Which devices are compatible with the UA-Hub-Gate?
A: It is compatible with UniFi smart devices, sensors, and other supported IoT devices, allowing seamless integration and automation.
Q: Can the UA-Hub-Gate be used for remote access?
A: Yes, it provides secure remote access to connected devices, enabling monitoring and control via the UniFi app or web interface.
Q: Is the UA-Hub-Gate suitable for enterprise and home networks?
A: Yes, it is designed for both enterprise and residential environments, supporting smart automation, network management, and device integration.
Q: How does the UA-Hub-Gate improve network and device management?
A: By centralising device connectivity and automation, it simplifies management, improves network organisation, and allows users to control multiple devices from a single interface.
