Ubiquiti UniFi G3 Reader Flex
The Ubiquiti Reader Flex is a durable NFC card reader with a built-in keypad, offering enhanced security and flexibility for modern access control systems. It supports multiple unlocking options, including PIN entry, NFC cards, the UniFi Identity mobile app, and Apple Touch Pass, ensuring convenience for all users. Entry and exit greeting messages add a professional touch, while the device maintains reliable performance in various conditions, even with moisture or most gloves.
Built to withstand harsh environments, the Reader Flex features IP55 weather resistance and operates in temperatures from -30 to 60°C. Its PoE connectivity allows seamless integration with the UniFi Access Hub, simplifying installation and management. Perfect for businesses requiring robust and adaptable security, the Reader Flex delivers a comprehensive access control solution within the UniFi ecosystem.
Tech Specs
Click here to see the Ubiquiti UniFi Reader Flex datasheet
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 84 x 84 x 40.8 mm (3.3 x 3.3 x 1.6") |
| NFC Card & Keyfob Access | ✓ |
| PIN Access | ✓ |
| Apple/Google Wallet | ✓ |
| Mobile Unlock | ✓ |
| NDAA Compliant | ✓ |
| UL 294 Level | Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| Weatherproofing | IP55 |
| Mechanical | |
| Weight | 165 g (5.8 oz) |
| Enclosure Material | Polycarbonate, glass, aluminium alloy |
| Mount Material | Polycarbonate, aluminum alloy |
| Mounting | Wall (Included) Gang-box, junction box (Optional) |
| Hardware | |
| Indoor and Outdoor Use | Yes |
| Ambient Operating Temperature | -30 to 60° C (-22 to 140° F) |
| Ambient Operating Humidity | 5 to 90% noncondensing |
| Networking Interface | (1) 10/100 MbE RJ45 port |
| Connectivity | BLE 4.1 NFC |
| Power Method | PoE UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU |
| Max. Power Consumption | 5W |
| Supported Voltage Range | 44—57V DC |
| ESD/EMP Protection | Air: ±15kV, contact: ±8kV |
| Sensors | (12) Capacitive buttons |
| Speaker | ✓ |
| LEDs | R/G/B/W Learn More |
| Button | (1) Factory-reset |
| NFC Frequency | 13.56 MHz |
| NFC Read Range | < 30 mm (1.18'') |
| NFC Technology | ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T and T5T ECP 2.0 |
| PoE Cabling Requirements | Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable. |
| UL 294 Statement | Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits. |
| CAN/ULC-60839-11-1 Grade | Grade assignment: I |
| Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
| Document Number / Revision | UA-G3-Flex V01 |
| Software | |
| Management Application | Access |
| Software Information | The software version can be checked at https://unifi.ui.com |
FAQs
Q. What type of device is the Ubiquiti UA-G3-Flex?
A: The UA-G3-Flex is a compact RFID keyfob designed for UniFi Access, providing secure and convenient contactless entry.
Q. What technology does the UA-G3-Flex use for authentication?
A: The UA-G3-Flex uses RFID technology to enable fast and secure authentication with compatible UniFi Access readers.
Q. How does the UA-G3-Flex integrate with UniFi Access?
A: The keyfob pairs with UniFi Access readers, allowing centralised management, real-time monitoring, and event logging through the UniFi Access platform.
Q. What durability and environmental features does the UA-G3-Flex offer?
A: The UA-G3-Flex is designed for daily use, lightweight, portable, and resistant to wear, making it ideal for long-term use.
Q. Can multiple UA-G3-Flex keyfobs be managed together?
A: Yes, multiple UA-G3-Flex keyfobs can be registered in UniFi Access, allowing scalable access control across small or large deployments.
