Ubiquiti UniFi U6 Enterprise
UniFi U6 Enterprise – Ceiling-Mount WiFi 6E Access Point with 6 GHz Support
The UniFi U6 Enterprise is a high-performance WiFi 6E access point designed to deliver seamless, multi-band connectivity in high-density environments. With 10 spatial streams and full support for the 6 GHz band, it provides faster speeds, lower latency, and greater efficiency for modern applications.
Offering up to 140 m² (1,500 ft²) of coverage and supporting more than 600 connected devices, the U6 Enterprise is ideal for offices, schools, conference centres, and other professional environments where capacity and reliability are essential.
Powered via PoE+ and featuring a 2.5 GbE uplink, the U6 Enterprise ensures high-speed backhaul and easy integration into UniFi-managed networks. Compact and discreet in design, it delivers enterprise-grade wireless performance with centralised management through the UniFi Network application.
Tech Specs
Click here for the UniFi U6 Enterprise datasheet.
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 220 x 48 mm |
| WiFi Standard | WiFi 6E |
| Spatial Streams | 10 |
| Coverage Area | 140 m² (1,500 ft²) |
| Max. Client Count | 600+ |
| Uplink | 2.5 GbE |
| Mounting | Ceiling, Wall (Pro Mount Included) |
| Power Method | PoE+ |
| Performance | |
| MIMO | 6 GHz: 4 x 4 (DL/UL MU-MIMO) 5 GHz: 4 x 4 (DL/UL MU-MIMO) 2.4 GHz: 2 x 2 (DL/UL MU-MIMO) |
| Max. Data Rate | 6 GHz: 4.8 Gbps (BW160) 5 GHz: 4.8 Gbps (BW160) 2.4 GHz: 573.5 Mbps (BW40) |
| Antenna Gain | 6 GHz: 6 dBi 5 GHz: 5.3 dBi 2.4 GHz: 3.2 dBi |
| Max. TX Power | 6 GHz: 26 dBm 5 GHz: 26 dBm 2.4 GHz: 22 dBm |
| Max. BSSIDs | 8 per Radio |
| Supported Data Rates | 802.11ax (WiFi 6/6E): 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) 802.11ac (WiFi 5): 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11n: 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) |
| Features | |
| Wireless Features | Wireless Meshing ✓ Band Steering ✓ 802.11v BSS Transition Management ✓ 802.11r Fast Roaming ✓ 802.11k Radio Resource Management (RRM) ✓ Advanced Radio Management ✓ Passpoint (Hotspot 2.0) ✓ Captive Hotspot Portal Custom Branding Landing Page ✓ Voucher Authentication ✓ Payment-Based Authentication ✓ External Portal Server Support ✓ Password Authentication ✓ Guest Network Isolation ✓ Private Pre-Shared Key (PPSK) ✓ WiFi Speed Limiting ✓ Client Device Isolation ✓ WiFi Schedules ✓ RADIUS over TLS (RadSec) ✓ Dynamic RADIUS-assigned VLAN ✓ |
| Hardware | |
| Max. Power Consumption | 22W |
| Supported Voltage Range | 44—57V DC |
| Networking Interface | (1) 1/2.5 GbE RJ45 port |
| Weight | Device: 960 g (2.1 lb) With mount: 1.1 kg (2.4 lb) |
| Management | Ethernet Bluetooth |
| Enclosure Material | Polycarbonate, aluminum |
| Mount Material | Stainless steel (SUS304) |
| LEDs | System: White/Blue |
| Channel Bandwidth | HT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz) |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, Anatel |
| Operating Frequency | US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz U-NII-5 to U-NII-8: 5925 - 7125 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5725 MHz 5925 - 7125 MHz (Depends on regulatory region) |
| Ambient Operating Temperature | -30 to 60° C (-22 to 140° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Software | |
| Application Requirements | UniFi Network Version 6.0.45 and later |
FAQs
Q: What is the Ubiquiti U6‑Enterprise and what is it used for?
A: The U6‑Enterprise is a high-performance WiFi 6 access point designed for enterprise environments, providing ultra-fast, reliable wireless coverage in high-density spaces.
Q: What frequency bands and wireless standards does the U6‑Enterprise support?
A: It supports tri-band WiFi 6 (2.4 GHz, 5 GHz, and 6 GHz) with 4×4 MU-MIMO, delivering maximum throughput, low latency, and superior client handling.
Q: How is the U6‑Enterprise powered and connected?
A: The device uses a Gigabit Ethernet port and is powered via 802.3at/af PoE+, providing both network connectivity and power over a single cable.
Q: How many clients can the U6‑Enterprise support simultaneously?
A: It is engineered for high-density environments and can support hundreds of concurrent clients while maintaining stable, high-speed connections.
Q: How is the U6‑Enterprise managed?
A: The U6‑Enterprise integrates with the UniFi Network Application, enabling centralised management, monitoring, firmware updates, and performance analytics.
