The Ubiquiti G3 Reader is a cutting-edge access control solution tailored for modern security needs. Supporting Apple Touch Pass, NFC cards, the UniFi Identity mobile app, and intuitive hand-wave unlocking, it offers versatile and seamless access options for any setting. Entry and exit greeting messages further enhance the user experience with a professional and welcoming touch.
Engineered for durability, the G3 Reader boasts an IP55 weather-resistant design, performing reliably in temperatures from -30 to 45°C. Its compact form factor and PoE connectivity make installation and maintenance straightforward, integrating seamlessly with the UniFi Access Hub for a hassle-free setup.
Tech Specs
Click here to see the Ubiquiti UniFi G3 Reader datasheet.
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 93 x 40 x 36.5 mm (3.7 x 1.6 x 1.4") |
| NFC Card & Keyfob Access | ✓ |
| Apple/Google Wallet | ✓ |
| Mobile Unlock | ✓ |
| Handwave Request to Exit | ✓ |
| NDAA Compliant | ✓ |
| UL 294 Level | Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| Weatherproofing | IP55 |
| Mechanical | |
| Weight | 82 g (2.9 oz) |
| Enclosure Material | Polycarbonate, glass |
| Mount Material | Aluminum alloy |
| Mounting | In-wall, gang box (Included) Junction box (Optional) |
| Hardware | |
| Indoor and Outdoor Use | Yes |
| Ambient Operating Temperature | -30 to 45° C (-22 to 113° F) |
| Ambient Operating Humidity | 5 to 90% noncondensing |
| Networking Interface | (1) 10/100 MbE RJ45 port |
| Connectivity | BLE 4.1 NFC |
| Power Method | PoE UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU |
| Max. Power Consumption | 5W |
| Supported Voltage Range | 48V DC |
| ESD/EMP Protection | Air: ±15kV, contact: ±8kV |
| Sensors | Proximity sensor |
| Speaker | ✓ |
| LEDs | R/G/B/W |
| Button | (1) Factory-reset |
| NFC Frequency | 13.56 MHz |
| NFC Read Range | < 30 mm (1.18'') |
| NFC Technology | ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T, T5T ECP 2.0 |
| PoE Cabling Requirements | Cat 5e minimum performance 26 AWG for patch cords; 24 AWG for horizontal/riser cable |
| UL 294 Statement | Compliance with IEEE 802.3 not verified; intended to comply with NEC ANSI/NFPA 70, Article 725.121 |
| CAN/ULC-60839-11-1 Grade | Grade assignment: I |
| Certifications | CE, FCC, IC, SRRC, UL 294, CAN/ULC-60839-11-1 |
| Document number / Revision | UA-G3, V01 |
| Software | |
| Management Application | Access |
| Software Information | The software version can be checked at https://unifi.ui.com |
FAQs
Q. What type of device is the Ubiquiti UA-G3?
A: The UA-G3 is an RFID access card designed to work with UniFi Access readers, enabling secure and convenient contactless entry control.
Q. What technology does the UA-G3 use for authentication?
A: The UA-G3 uses RFID technology for secure, contactless authentication with compatible UniFi Access readers.
Q. How does the UA-G3 integrate with UniFi Access?
A: The card integrates with UniFi Access readers, allowing centralised management, real-time monitoring, and event logging via the UniFi Access platform.
Q. What durability and environmental features does the UA-G3 offer?
A: The UA-G3 is built for daily use, resistant to wear and tear, and suitable for indoor and light-duty outdoor environments.
Q. Can multiple UA-G3 cards be managed simultaneously?
A: Yes, multiple UA-G3 cards can be registered and managed within UniFi Access, allowing scalable user and access management across a facility.
