Tycon Systems TP-DCDC-1248GD
Please contact us for stocking information.
TP-DCDC-1248GD – DC to DC Converter with Integrated Gigabit PoE Injector
The TP-DCDC-1248GD from Tycon is a high-efficiency DC to DC converter with an integrated IEEE802.3af PoE injector, designed for delivering power and data from a 12VDC or 24VDC source such as a battery system or vehicle. It regulates and protects output voltage for long-term reliability, making it suitable for a range of networking and industrial applications.
The unit features dual (+) and (-) inputs, allowing connection of both primary and backup power sources for increased redundancy. Built-in protections guard against surge, short circuit, and overload, while input and output isolation ensures system safety. An optional metal enclosure variant is available for harsh environments.
Supporting gigabit data throughput, the TP-DCDC-1248GD delivers PoE power on Ethernet pins 4,5 (V+) and 7,8 (V-), with up to 24W output depending on the model. This makes it ideal for powering IP cameras, wireless access points, and other PoE-enabled devices in mobile, remote, or off-grid deployments.
Tech Specs
View the Tycon Systems Gigabit DC to DC Converter datasheet here.
| Device Specifications | |
|---|---|
| Ship Weight | 0.35 lbs |
| Ship Dimensions | 5 × 4 × 2 in |
| Input Voltage | 12/24 VDC |
| Output Voltage/Type | 48V 802.3af PoE |
| Output Power | 17W |
| Network Speed | Gigabit |
| Temperature Range | -30C to +60C |
FAQs
Q: What is the TP-DCDC-1248GD DC to DC converter used for?
A: The TP-DCDC-1248GD from Tycon Power is designed to convert 12VDC or 24VDC input to 48V IEEE802.3af PoE output, supplying both data and power to PoE-enabled devices such as IP cameras, wireless access points, and VoIP phones. It is ideal for mobile, remote, or off-grid deployments.
Q: Does the TP-DCDC-1248GD support backup power inputs?
A: Yes. The TP-DCDC-1248GD features dual (+) and (–) inputs, allowing the connection of both primary and backup DC power sources. This redundancy helps maintain uninterrupted operation in critical applications.
Q: What protections are built into the TP-DCDC-1248GD?
A: The TP-DCDC-1248GD includes surge protection, short-circuit protection, overload protection, and input/output isolation. These features safeguard both the converter and connected equipment for long-term reliability.
Q: How much power can the TP-DCDC-1248GD deliver over PoE?
A: The TP-DCDC-1248GD can deliver up to 24W depending on the model, providing PoE power on Ethernet pins 4,5 (V+) and 7,8 (V–), with full gigabit data throughput.
Q: Is the TP-DCDC-1248GD suitable for outdoor or industrial use?
A: The TP-DCDC-1248GD can be supplied with an optional metal enclosure variant, making it more suitable for harsh or industrial environments. Combined with its wide operating temperature range, it can be deployed in challenging conditions.
