Ubiquiti UniFi SuperLink
The Ubiquiti SuperLink is a proprietary, super long-range wireless gateway designed for UniFi Protect Sensors, delivering low-latency, high-performance connectivity. With support for 96 SuperLink clients and a 2 km link range (line of sight), it ensures reliable sensor communication over vast distances. Additionally, it connects 7 UP-Sense (BLE) devices with improved long-range BLE coverage, comparable to WiFi range. The SuperLink is powered via PoE or USB Type-C and offers versatile mounting options for wall and DIN rail installations. Built for scalability, it’s the ultimate solution for extending UniFi Protect sensor networks.
Any EU products are supplied with the appropriate UK power method at no extra cost.
Tech Specs
View the Ubiquiti UniFi SuperLink datasheet here.
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | With antenna: 159.3 x 81.9 x 26 mm (6.3 x 3.2 x 1") With DIN rail mount: 159.3 x 81.9 x 38.5 mm (6.3 x 3.2 x 1.5") With wall mount: 159.3 x 81.9 x 30.5 mm (6.3 x 3.2 x 1.2") |
| Mounting | Wall and DIN rail mount |
| UniFi Application Suite | Protect |
| Performance | |
| Networking Interface | (1) 10/100 MbE RJ45 port |
| Connectivity | Bluetooth® 5.2 SuperLink (Proprietary) |
| Operating Frequency | US: 915.6–927.6 MHz EU: 865.1–869.5 MHz Bluetooth: 2400–2480 MHz |
| Antenna Gain | Bluetooth: 3 dBi SuperLink: 2 dBi |
| Max. TX Power | Bluetooth: 10 dBm SuperLink: 27 dBm |
| Max. Range | Bluetooth: Up to 100 m (328 ft) SuperLink: 2 km (1.2 mi) |
| Max. Client Count | Bluetooth: 7 SuperLink: 96 |
| Hardware | |
| Max. Power Consumption | 3.4W |
| Power Method | PoE USB Type-C, 5V, 1A (Optional) |
| Weight | 179 g (6.3 oz) |
| Enclosure Material | Polycarbonate, aluminum alloy |
| Mount Material | Polycarbonate |
| Buttons | (1) Factory-reset |
| LEDs | (1) Status: B/W |
| Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| NDAA Compliant | ✓ |
| Software | |
| Application Requirements | Web Application: UniFi Protect Mobile App: UniFi Protect iOS™ and Android™ |
FAQs
Q1: What is the Ubiquiti UP-SuperLink and what is it used for?
A: The Ubiquiti UP-SuperLink is a long-range wireless gateway designed to connect UniFi Protect sensors over extended distances. It enables reliable communication between multiple sensors and a UniFi Protect controller in larger or distributed installations.
Q2: How does the Ubiquiti UP-SuperLink connect to sensors and other devices?
A: It uses a combination of proprietary SuperLink technology for ultra-long-range wireless links and Bluetooth for shorter-range connectivity, allowing it to communicate with a large number of compatible sensors and devices.
Q3: What network interfaces and power options does the Ubiquiti UP-SuperLink have?
A: The device includes a single Ethernet port for PoE networking and supports power either through Power-over-Ethernet or USB-C, giving flexibility in how it is deployed and powered within a network.
Q4: How many sensors can the Ubiquiti UP-SuperLink support and what range does it achieve?
A: The UP-SuperLink can support dozens of wireless sensor connections thanks to its extended-range SuperLink radio. Under ideal conditions, it can reliably link sensors at distances significantly greater than traditional Bluetooth connections.
Q5: What physical and installation features does the Ubiquiti UP-SuperLink offer?
A: The gateway comes in a compact housing with wall-mount and DIN-rail mounting options, making it easy to install in cabinets or on surfaces. It also includes LED indicators for status monitoring and is designed for consistent operation in typical indoor environments.
