The LTU Pro is a high-performance PtMP subscriber station with advanced industrial design and technology. Utilising Ubiquiti's LTU technology and a high-gain dish, it offers flexibility in channel width and can avoid interference in a PtMP environment with the LTU-Pro and LTU-Lite.
Tech Specs
Click here for the Ubiquiti LTU Pro datasheet.
| Device Specifications | |
|---|---|
| Mechanical | |
| Dimensions | 316.5 x 316.5 x 174.3 mm (12.5 x 12.5 x 6.9") |
| Weight | 1.3 kg (2.9 lb) |
| Enclosure Material | UV-stabilized polycarbonate |
| Mounting | Pole mount (Kit included) |
| Wind Loading | 150 N at 200 km/h (33.72 lbf at 125 mph) |
| Wind Survivability | 200 km/h (125 mph) |
| Hardware | |
| Networking Interface | (1) GbE RJ45 port |
| Power Method | Passive PoE 2-pair (4, 5+; 7, 8-) |
| Power Supply | 24V, 0.5A gigabit PoE adapter (Included) |
| Supported Voltage Range | 22–27V DC |
| Max. Power Consumption | 9W |
| ESD/EMP Protection | Air/contact: ± 24kV |
| Ambient Operating Temperature | -40 to 60° C (-40 to 140° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| NDAA Compliant | Yes |
| Software | |
| Modes | PtMP CPE, PtP* *1.5.1 and later 1.5.x series firmware |
| Services | SNMP, SSH, dynamic DNS, webserver, remote log, ping watchdog |
| Utilities | airView®, speed test, alignment, discovery, ping, traceroute, cable test, constellation |
| Auto Distance Adjustment | Yes |
| Auto Power Adjustment | Yes |
| Network | Bridge/Router* mode *Router mode is available in PtMP CPE mode only |
| Security | Yes |
| Statical Reporting | Yes |
| Management Interface | Bluetooth management for easy setup over UISP App WEB UI Minimum software requirements: Any modern web browser, iOS™ or Android™ based smartphone |
| System | |
| Maximum Throughput | 900+ Mbps* *FW version 2.3.0 and later |
| Encryption | WPA2-PSK (AES) |
| Uplink/Downlink Ratio | 25/75, 33/67, 50/50 |
| RF | |
| Operating Frequency | US/CA: U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz EU: 2400 - 2483.5 MHz, 5150 - 5875 MHz Worldwide: 2400 - 2483.5 MHz, 4800 - 6200 MHz *Depends on regulatory region |
| Max. Conducted TX Power | 22 dBm (per chain) |
| Channel Bandwidth | 10/20/30/40/50/60/80/100 MHz* *FW version 2.3.0 and later |
| Antenna Gain | 24 dBi |
| Beamwidth | 14° |
| Sidelobe Level | -10 dB |
| Front-to-Back Ratio | 27 dB |
FAQs
Q1: What is the Ubiquiti LTU-Pro?
A1: The Ubiquiti LTU-Pro is a high-performance 5 GHz PtMP (Point-to-Multipoint) client radio designed for outdoor wireless networks. It features a 24 dBi integrated antenna, supports 900+ Mbps throughput, and utilizes Ubiquiti's proprietary LTU technology for advanced RF performance.
Q2: What are the key specifications of the LTU-Pro?
A2:
-
Frequency Range: 5.15–5.85 GHz
-
Gain: 24 dBi
-
Beamwidth: 14°
-
Maximum Throughput: 900+ Mbps
-
Channel Widths: 10/20/30/40/50 MHz
-
Modulation: 1024-QAM
-
Power Consumption: 9W
-
Power Supply: 24V Passive PoE (Gigabit PoE adapter included)
-
Operating Temperature: -40°C to 60°C
-
Mounting: Pole mount (kit included)
-
Certifications: CE, FCC, IC
-
ESD Protection: ±24kV
-
Weatherproofing: IPX6
-
Bluetooth Management: Yes
Q3: How does the LTU-Pro compare to other Ubiquiti devices?
A3: The LTU-Pro offers higher throughput and advanced RF performance compared to traditional 802.11-based devices. Unlike airMAX or airFiber products, the LTU-Pro utilizes Ubiquiti's proprietary LTU technology, providing improved spectral efficiency and reduced latency in PtMP deployments.
Q4: What software features does the LTU-Pro support?
A4: The LTU-Pro supports various software features, including:
-
SNMP
-
SSH
-
Dynamic DNS
-
Web interface
-
Remote logging
-
Ping watchdog
-
Utilities such as airView®, speed test, alignment, discovery, ping, traceroute, cable test, and constellation
-
Auto distance and power adjustment
-
Router mode support (available in PtMP CPE mode)
-
Bluetooth management via the UISP app
Q5: How is the LTU-Pro installed and powered?
A5: The LTU-Pro is powered via 24V passive PoE, with a Gigabit PoE adapter included in the package. It features a pole mount kit for easy installation and alignment. The device also supports Bluetooth management for convenient setup using the UISP app.
