Ubiquiti UniFi AC Pro
UniFi AC Pro – Ceiling-Mount WiFi 5 Access Point for High-Density Networks
The UniFi AC Pro is a ceiling-mounted WiFi 5 access point designed to deliver fast, reliable connectivity in large office and commercial environments. With six spatial streams and coverage up to 140 m² (1,500 ft²), it supports over 250 connected devices, making it ideal for high-density deployments.
Powered via PoE and equipped with a GbE uplink, the AC Pro integrates seamlessly into UniFi-managed networks for centralised configuration, monitoring, and management. Its dual-band WiFi 5 technology offers stable performance for bandwidth-heavy applications such as video conferencing, cloud collaboration, and VoIP.
Robust and discreet in design, the UniFi AC Pro is suitable for mounting in offices, conference centres, retail spaces, and other professional settings where consistent, high-capacity wireless access is essential.
Tech Specs
Click here for the UniFi AC Pro datasheet.
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | Ø196.7 x 35 mm (Ø7.7 x 1.4") |
| WiFi Standard | WiFi 5 |
| Spatial Streams | 6 |
| Coverage Area | 140 m² (1,500 ft²) |
| Max. Client Count | 250+ |
| Uplink | GbE |
| Mounting | Ceiling, Wall (Pro Mount Supported) |
| Power Method | PoE |
| Performance | |
| MIMO | 5 GHz: 3 x 3 (DL MU-MIMO) 2.4 GHz: 3 x 3 (DL MU-MIMO) |
| Max. Data Rate | 5 GHz: 1.3 Gbps (BW80) 2.4 GHz: 450 Mbps (BW40) |
| Antenna Gain | 5 GHz: 3 dBi 2.4 GHz: 3 dBi |
| Max. TX Power | 5 GHz: 22 dBm 2.4 GHz: 22 dBm |
| Max. BSSIDs | 8 per Radio |
| Supported Data Rates | 802.11ac (WiFi 5): 6.5 Mbps to 1.3 Gbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80) 802.11n: 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40) |
| Features | |
| Wireless Meshing | ✓ |
| Band Steering | ✓ |
| 802.11v BSS Transition Management | ✓ |
| 802.11r Fast Roaming | ✓ |
| 802.11k Radio Resource Management (RRM) | ✓ |
| Advanced Radio Management | ✓ |
| Passpoint (Hotspot 2.0) | ✓ |
| Captive Hotspot Portal | Custom Branding Landing Page ✓ Voucher Authentication ✓ Payment-Based Authentication ✓ External Portal Server Support ✓ Password Authentication |
| Guest Network Isolation | ✓ |
| Private Pre-Shared Key (PPSK) | ✓ |
| WiFi Speed Limiting | ✓ |
| Client Device Isolation | ✓ |
| WiFi Schedules | ✓ |
| RADIUS over TLS (RadSec) | ✓ |
| Dynamic RADIUS-assigned VLAN | ✓ |
| Hardware | |
| Max. Power Consumption | 9W |
| Includes PoE Adapter | ✓ |
| Supported Voltage Range | 44—57V DC |
| Networking Interface | (2) GbE RJ45 ports |
| Weight | Device: 350 g (12.4 oz) With mount: 450 g (15.9 oz) |
| Management | Ethernet |
| Enclosure Material | Polycarbonate |
| LEDs | System, Status |
| Channel Bandwidth | HT 20/40, VHT 20/40/80 (MHz) |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, Anatel |
| Operating Frequency | US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5725 MHz |
| Ambient Operating Temperature | -10 to 70° C (14 to 158° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
FAQs
Q: What is the Ubiquiti UAP‑AC‑Pro and what is it used for?
A: The UAP‑AC‑Pro is a dual-band WiFi access point designed for indoor and outdoor deployment, delivering high-speed wireless coverage for homes, offices, and enterprise networks.
Q: What wireless standards and frequencies does the UAP‑AC‑Pro support?
A: It supports IEEE 802.11a/b/g/n/ac on both 2.4 GHz and 5 GHz bands, using 3×3 MIMO to provide maximum throughput of 450 Mbps on 2.4 GHz and 1300 Mbps on 5 GHz.
Q: How is the UAP‑AC‑Pro powered and connected?
A: The device uses a Gigabit Ethernet port and supports 802.3af/at PoE, enabling a single-cable solution for both power and data.
Q: How many clients can the UAP‑AC‑Pro support simultaneously?
A: It can support hundreds of concurrent clients, making it suitable for medium to high-density deployments in offices or public areas.
Q: How is the UAP‑AC‑Pro managed?
A: The UAP‑AC‑Pro integrates with the UniFi Network Application, allowing centralised configuration, performance monitoring, firmware updates, and network analytics.
