Ubiquiti UniFi UNAS 2
Please contact us for stocking information.
UniFi UNAS 2 – Compact High-Performance NAS for UniFi Environments
The UniFi UNAS 2 is a compact, high-performance network-attached storage device designed for seamless file management and backup within UniFi environments. Featuring two 3.5" HDD bays, it delivers reliable and scalable storage suited to small business and professional use cases where simplicity and performance are key.
Equipped with 2.5 GbE networking and USB-C connectivity, the UNAS 2 provides fast data access and flexible integration into modern networks. An included PoE++ adapter simplifies deployment, allowing both power and connectivity to be delivered efficiently while reducing cabling complexity.
Built to integrate cleanly with UniFi systems, the UNAS 2 enables efficient file sharing, data protection, and media storage across connected devices. Its space-saving design and advanced connectivity options make it a practical choice for organisations seeking enterprise-grade storage performance in a compact form factor.
Any EU products are supplied with the appropriate UK power method at no extra cost.
Tech Specs
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 135 x 129 x 223.7 mm (5.3 x 5.1 x 8.8") |
| Storage Capacity | (2) 3.5" drive bays |
| Networking Interface | (1) 2.5 GbE RJ45 (2.5G/1G/100M/10M) |
| Expansion Port | (1) 5 Gbps USB-C |
| Form Factor | Desktop |
| Hardware | |
| Hard Drive Capacity | (2) 3.5" HDD support |
| USB Drive | ✓ |
| Max. Power Budget for Drives | 52W |
| Max. Power Consumption | 60W |
| Power Method | PoE++ |
| Power Supply | 60W PoE++ adapter (Included) |
| Processor | Quad-Core ARM® Cortex®-A55 at 1.7 GHz |
| Memory | 4 GB |
| Management | Ethernet |
| RF Interface | Bluetooth 4.1 |
| Display | 1.47" color LCM |
| Weight | 1.3 kg (2.85 lb) |
| Enclosure Material | Polycarbonate |
| LEDs | System ✓ |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 10 to 90% noncondensing |
| NDAA Compliant | ✓ |
| Certifications | FCC, CE, IC |
| Software | |
| Application Requirements | UniFi Drive Version 3.1.7 and later |
| Mobile App | iOS™ version 10.28.0 and later Android™ version 10.28.3 and later |
| Supported File Protocols | NFS ✓ SMB ✓ |
| RAID Type | RAID 1 |
| RAID Group | Single |
| Personal Drive & Shared Drive | ✓ |
| File Encryption | ✓ |
| Backup to Remote UNAS | ✓ |
| Backup to CIFS/SMB Server | ✓ |
| Backup to Cloud Services | Google Drive, OneDrive, Dropbox, Amazon S3, Backblaze B2, Wasabi ✓ |
| Snapshots | ✓ |
| Share Links | ✓ |
| Time Machine Backup | ✓ |
| Client App Support | ✓ |
| User Groups | ✓ |
FAQs
Q1: What is the Ubiquiti UNAS‑2 and what is it used for?
A: The Ubiquiti UNAS‑2 is a network‑attached storage (NAS) enclosure designed to add high‑capacity storage to UniFi Protect and UniFi network systems. It provides centralized video and data storage for surveillance and network applications.
Q2: How many hard drives can the Ubiquiti UNAS‑2 accommodate?
A: The UNAS‑2 features two drive bays, allowing users to install two standard SATA hard drives or SSDs to scale storage capacity based on their needs.
Q3: How does the Ubiquiti UNAS‑2 connect to a network?
A: The UNAS‑2 connects to your network via Gigabit Ethernet, enabling fast data access and sharing across UniFi devices and clients on the same network.
Q4: What storage and data protection features does the Ubiquiti UNAS‑2 support?
A: The NAS enclosure supports RAID configurations when two drives are installed, offering options such as RAID 1 for mirrored redundancy or JBOD for maximum capacity.
Q5: What installation and physical features does the Ubiquiti UNAS‑2 have?
A: The device is designed with a compact chassis that fits easily on a shelf or in a network cabinet. Its drive bays are accessible for straightforward installation and maintenance.
