MikroTik RB4011iGS+5HacQ2HnD-IN Dual-Band Gigabit Ethernet Router with IPSec
Please contact us for stocking information.
The MikroTik RB4011iGS+5HacQ2HnD-IN is a robust and highly efficient dual-band dual-chain router with 10 Gigabit ports and a 10Gbps SFP+ interface. It boasts IPsec hardware acceleration and is powered by a quad-core Cortex A15 CPU, similar to the one used in MikroTik's RB1100AHx4 unit. With 1GB of RAM, PoE output on port #10, and a sleek matte black solid metal enclosure, this unit is perfect for professional settings. It offers a supported data rate of up to 1733 Mbps in the 5GHz band, and even has a dual-chain 2GHz wireless card in the miniPCI-e slot for legacy devices.
Tech Specs
Click here for the RB4011iGS+5HacQ2HnD-IN datasheet.
| Device Specifications | |
|---|---|
| Specifications | |
| Product code | RB4011iGS+5HacQ2HnD-IN |
| Architecture | ARM 32bit |
| CPU | AL21400 |
| CPU core count | 4 |
| CPU nominal frequency | auto (533–1900 MHz) |
| Switch chip model | RTL8367SB |
| Dimensions | 228 x 120 x 30 mm |
| RouterOS license | 5 |
| Operating System | RouterOS v7 |
| Size of RAM | 1 GB |
| Storage size | 512 MB |
| Storage type | NAND |
| MTBF | Approximately 200'000 hours at 25°C |
| Tested ambient temperature | -40°C to 45°C |
| IPsec hardware acceleration | Yes |
| Suggested price | $275.00 |
| Wireless Capabilities | |
| 5 GHz Max data rate | 1733 Mbit/s |
| 5 GHz number of chains | 4 |
| 5 GHz standards | 802.11a/n/ac |
| 5 GHz antenna gain | 3 dBi |
| 5 GHz chip model | QCA9984 |
| 5 GHz generation | Wi-Fi 5 |
| 2.4 GHz Max data rate | 300 Mbit/s |
| 2.4 GHz number of chains | 2 |
| 2.4 GHz standards | 802.11b/g/n |
| 2.4 GHz antenna gain | 3 dBi |
| 2.4 GHz chip model | R11e-2HnD |
| 2.4 GHz generation | Wi-Fi 4 |
| WiFi speed | AC2000 |
| Ethernet | |
| 10/100/1000 Ethernet ports | 10 |
| Fiber | |
| SFP+ ports | 1 |
| Peripherals | |
| MiniPCI-e slots | 1 |
| Serial console port | RJ45 |
| Powering | |
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input voltage | 12–57 V |
| Max power consumption | 44 W |
| Max power consumption without attachments | 23 W |
| PoE in | Passive PoE |
| Cooling type | Passive |
| PoE in input voltage | 18–57 V |
| PoE-out | |
| PoE-out ports | Ether10 |
| PoE out | Passive PoE up to 57V |
| Low voltage PoE-Out current limit | 600 mA |
| High voltage PoE-Out current limit | 420 mA |
| Max total out (A) | 600 mA |
| Certification & Approvals | |
| Certification | CE, FCC, IC, EAC, ROHS |
| IP | IP20 |
| Other | |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
FAQs
Q: What is the MikroTik RB4011iGS+5HacQ2HnD‑IN used for?
A: The RB4011iGS+5HacQ2HnD‑IN is a high‑end indoor router designed for demanding wired and wireless networks. It offers ten Gigabit Ethernet ports, an SFP+ 10 Gbps slot, and dual‑band WiFi making it ideal for offices, AP aggregation or advanced home networks.
Q: What wired and wireless connectivity does the RB4011iGS+5HacQ2HnD‑IN support?
A: It supports ten 10/100/1000 Mbps LAN ports, one SFP+ port for 10 Gbps fibre or breakout, dual‑band WiFi (2.4 GHz up to 300 Mbps with 2‑chain and 5 GHz up to 1733 Mbps with 4‑chain), allowing full‑speed wired and wireless integration.
Q: What power and PoE features does the RB4011iGS+5HacQ2HnD‑IN offer?
A: It supports DC jack input (12‑57 V) or passive PoE‑in on port 1 (18‑57 V). It also provides PoE‑out from port 10 (passive up to 57 V) to power another device such as an access point. Max power consumption is about 44 W under full load including PoE‑out.
Q: What are the core hardware and management features of the RB4011iGS+5HacQ2HnD‑IN?
A: It has a quad‑core ARM Cortex A15 CPU (nominal 1.4 GHz), 1 GB RAM, 512 MB NAND storage, runs RouterOS v7 with Licence Level 5, supports IPsec hardware acceleration, and is enclosed in a compact metal chassis (228 × 120 × 30 mm) suitable for desktop, wall or rack‑mount use.
Q: In what scenarios is the RB4011iGS+5HacQ2HnD‑IN best deployed?
A: It’s ideal for small offices, branch networks or advanced home setups requiring a mix of high‑speed wired ports and strong WiFi coverage. It also suits environments needing fibre uplink via SFP+ and PoE‑powered downstream devices like access points or cameras.
