RF elements StarterDish UM Antennas
The RF Elements StarterDish UM Antennas are high-performance parabolic dish antennas designed for reliable point-to-point wireless links. Built to withstand harsh outdoor environments, they feature IP65-rated construction and support pole mounting with diameters from 20 to 55 mm, making them a versatile choice for a range of installations.
Compatible with a variety of popular wireless devices, including RF elements StarterAdapter™ SMA, Mimosa® C5x, and Ubiquiti Networks® PrismStation™ 5AC and IsoStation™ 5, the StarterDish UM enables robust, high-gain connections for long-distance links. Its precise parabolic design ensures focused signal transmission and reception, minimising interference and maximising throughput.
Rated to operate in temperatures from –35 to +55 °C and survive winds up to 160 km/h, these antennas are ideal for branch sites, rural installations, or any deployment requiring dependable outdoor connectivity. By pairing with compatible radios, the StarterDish UM delivers efficient, high-capacity links that maintain performance even in challenging conditions.
Tech Specs
| Device Specifications | |
|---|---|
| Antenna Connection | Waveguide Port |
| Antenna Type | Parabolic Dish |
| Environmental | IP65 |
| Pole Mounting Diameter | 20–55 mm |
| Temperature | -35 to +55 °C (-31°F to +131°F) |
| Wind Survival | 160 km/h |
| Antenna Compatibility | RF elements: StarterAdapter™ SMA Mimosa by Airspan: C5x Ubiquiti Networks: PrismStation 5AC, IsoStation 5AC, IsoStation M5 StarterDish Series |
| StarterDish 21 UM | Product ID: STD-21-UM-5PACK Gain: 21 dBi Frequency Range: 5150 – 5950 MHz |
| StarterDish 24 UM | Product ID: STD-24-UM-5PACK Gain: 24 dBi Frequency Range: 5150 – 6400 MHz |
| StarterDish 27 UM | Product ID: STD-27-UM-5PACK Gain: 27 dBi Frequency Range: 5150 – 6400 MHz |
FAQs
Q1: What are RF Elements StarterDish UM Antennas and what are they used for?
A: RF Elements StarterDish UM Antennas are compact, high‑efficiency parabolic grid antennas designed for point‑to‑point and point‑to‑multipoint wireless links. They are used to extend range and improve signal quality for compatible wireless radios in outdoor networks.
Q2: What frequency bands do StarterDish UM Antennas support?
A: These antennas are typically designed for UHF and lower GHz bands used by common wireless access points and bridges. Their design focuses on balanced performance and range in standard outdoor Wi‑Fi and ISP frequency ranges.
Q3: What performance benefits do RF Elements StarterDish UM Antennas offer?
A: StarterDish UM Antennas deliver focused gain and narrow beamwidth, which helps achieve longer links with reduced interference. Their parabolic design enhances signal directivity, improving throughput and stability over distance.
Q4: How are StarterDish UM Antennas installed and mounted?
A: These antennas include mounting hardware that supports pole and mast installation, allowing precise alignment for optimal line‑of‑sight performance. Their robust build is suitable for outdoor use in fixed wireless networks.
Q5: What applications are StarterDish UM Antennas ideal for?
A: They are ideal for backhaul links, campus connectivity, rural broadband, and wireless ISP (WISP) deployments where a reliable, high‑gain antenna is needed to bridge long distances between network nodes.
