Ubiquiti UniFi Dream Router 5G Max – 5G WiFi 7 Cloud Gateway with 10G SFP+
The Ubiquiti UniFi Dream Router 5G Max is a desktop Cloud Gateway that combines high-speed 5G connectivity with WiFi 7 and integrated switching for all-in-one network deployment. Supporting 5G speeds of up to 3.4 Gbps, it enables flexible WAN configurations with up to four WAN options for primary, failover, or load-balanced connectivity.
It features a 10G SFP+ port for high-bandwidth uplinks and a built-in 4-port 2.5 GbE switch, including one PoE port for powering connected devices. Tri-radio WiFi 7 with 6 spatial streams across 2.4 GHz, 5 GHz, and 6 GHz delivers fast, consistent wireless performance for modern networks.
Running the full UniFi application suite, the Dream Router 5G Max supports over 30 UniFi devices and 300+ connected users, with SD card storage for added flexibility. Advanced security features include real-time threat detection with IDS/IPS throughput of up to 2.3 Gbps, providing reliable protection for both inbound and outbound traffic.
Tech Specs
View the complete UniFi Dream Router 5 Max datasheet here.
| Device Specifications | |
|---|---|
| Dimensions | 110 x 110 x 250 mm (4.3 x 4.3 x 9.8") |
| NVR Storage | Pre-installed 64 GB microSD |
| Expansion Slot | MicroSD card |
| PoE Budget | 15.4W |
| Max. PoE Wattage per Port | PoE: 15.4W |
| PoE Mode Voltage Range | 44–57V |
| Max. Power Consumption | 34.5W (excluding PoE output) |
| Power Method | DC jack (54V DC / 1.1A) |
| Power Supply | 54V DC / 1.1A (adapter included) |
| Supported Voltage Range | 100–240V AC |
| Heat Dissipation | 115 BTU/hr (excluding PoE output) |
| Processor | Quad-core ARM Cortex-A53 at 1.5 GHz |
| System Memory | 3 GB |
| Weight | 1.4 kg (3.1 lb) |
| Enclosure Material | Polycarbonate |
| LCM Display | 4.7" touchscreen |
