Ubiquiti UniFi Dream Router 7
UniFi Dream Router 7 – Desktop 10G Cloud Gateway with Integrated WiFi 7
The Ubiquiti Dream Router 7 is a high-performance 10G Cloud Gateway with an integrated WiFi 7 access point, offering 6 spatial streams and 6 GHz support for ultra-fast, low-latency connectivity.
Designed for seamless UniFi network management, it runs the full UniFi application suite, allowing you to control 30+ UniFi devices and support 300+ clients from a single, compact desktop unit.
Featuring a 4-port switch with PoE, a 10G SFP+ and 2.5 GbE RJ45 WAN port, plus 64 GB microSD storage (upgradable), the Dream Router 7 delivers advanced networking, security, and storage in one powerful solution.
Any EU products are supplied with the appropriate UK power method at no extra cost.
Tech Specs
View the Ubiquiti UniFi Dream Router 7 datasheet here.
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 110 x 184.1 mm (4.3 x 7.3") |
| UniFi Application Suite | Network ✓ Protect ✓ Access ✓ Talk ✓ Connect ✓ |
| Managed UniFi Devices | 30+ |
| Managed Cameras | (5) HD (2) 2K (1) 4K |
| Simultaneous Users Connected | 300+ |
| Max. WAN Port Count | 4 |
| Default WAN Ports | (1) 10G SFP+ (1) 2.5 GbE RJ45 |
| Port Layout | 2.5 GbE RJ45: 4 (1 PoE) (2.5G/1G/100M/10M) 10G SFP+: 1 (10G/1G) |
| IDS/IPS Throughput | 2.3 Gbps |
| Form Factor | Compact desktop |
| Coverage Area | 160 m² (1,750 ft²) |
| Security | |
| Features | Stateful Firewall ✓ Application-Aware Layer 7 Firewall ✓ DPI & Traffic Identification ✓ Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) ✓ Content Filtering ✓ Intrusion Prevention (IPS/IDS) ✓ Ad Blocking ✓ IDS/IPS Signatures: 20,000+ with CyberSecure VLAN/Subnet-based Traffic Segmentation ✓ |
| VPN & SD-WAN | |
| Supported Protocols | License-Free SD-WAN ✓ Site-to-Site VPN: Site Magic ✓ IPsec ✓ OpenVPN ✓ Identity Endpoint One-Click VPN ✓ Teleport Zero-Configuration VPN ✓ WireGuard ✓ L2TP ✓ VPN Client: OpenVPN ✓, WireGuard ✓ |
| Networking | |
| Features | Multi-WAN Load Balancing ✓ Dynamic Routing: OSPF ✓ Advanced QoS ✓ Multicast DNS (mDNS) ✓ Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) ✓ Integrated RADIUS Server ✓ RADIUS over TLS (RadSec) ✓ Additional Internet Failover with UniFi LTE Backup ✓ Internet Quality and Outage Reporting ✓ MAC Address Table Size: 2,000 Policy-based WAN and VPN Routing ✓ Customizable DHCP Server ✓ IPv6 ISP Support ✓ IGMP Proxy ✓ |
| Integrated WiFi | |
| WiFi Standard | 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7) |
| Throughput | 6 GHz: 5.7 Gbps 5 GHz: 4.3 Gbps 2.4 GHz: 688 Mbps |
| MIMO | 6 GHz: 2 x 2 (DL/UL MU-MIMO) 5 GHz: 2 x 2 (DL/UL MU-MIMO) 2.4 GHz: 2 x 2 (DL/UL MU-MIMO) |
| Antenna Gain | 6 GHz: 6 dBi 5 GHz: 7 dBi 2.4 GHz: 5 dBi |
| Max. TX Power | 6 GHz: 24 dBm 5 GHz: 26 dBm 2.4 GHz: 23 dBm |
| Wireless Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
| Max. BSSIDs | 4 per Radio |
| Supported Data Rates | 802.11a: 6–54 Mbps 802.11b: 1–11 Mbps 802.11g: 6–54 Mbps 802.11n: 6.5 Mbps to 300 Mbps 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps 802.11ax (WiFi 6/6E): 7.3 Mbps to 2.4 Gbps 802.11be (WiFi 7): 7.3 Mbps to 5.7 Gbps |
| Hardware | |
| NVR Storage | Pre-installed 64GB microSD for NVR Expansion Slot: MicroSD Card |
| PoE Budget | 15.4W |
| Max. Power Consumption | 26W (Excluding PoE output) |
| Power Method | Universal AC input, 100—240VAC, 1.5A Max, 50/60 Hz |
| Power Supply | AC/DC, Internal, 50W |
| Processor | Quad-core ARM® Cortex®-A53 at 1.5 GHz |
| System Memory | 3 GB |
| Weight | 1.1 kg (2.4 lb) |
| Enclosure Material | Polycarbonate |
| LCM Display | 0.96" status display |
| Management | Ethernet Bluetooth |
| LEDs | System ✓ |
| Button | (1) Factory-reset |
| ESD/EMP Protection | Air: ±8kV, contact: ±4kV |
| Ambient Operating Temperature | -10 to 40° C (14 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC |
| Software | |
| VLAN | 802.1Q |
| Guest Traffic Isolation | ✓ |
| Application Requirements | UniFi Network Version 9.0.108 and later |
FAQs
Q: What is the Ubiquiti UDR7 Dream Router 7 and what does it combine?
A: The UDR7 (UniFi Dream Router 7) is an all‑in‑one cloud gateway that merges a 10 G SFP+ WAN, multi‑gigabit PoE switch and tri‑band WiFi 7 access point with integrated NVR storage, all managed via UniFi OS.
Q: How fast is the WiFi on the UDR7 and what standards does it support?
A: The UDR7 supports tri‑band WiFi 7 (802.11be) across 2.4 GHz, 5 GHz, and 6 GHz, with 2×2 MU‑MIMO in each band and combined wireless throughput up to ~10.6 Gbps.
Q: What wired connections and PoE capabilities does the UDR7 include?
A: It includes 1×10 G SFP+ WAN port, 1×2.5 G RJ45 WAN/LAN port, and 3×2.5 G LAN ports—one of which supports 802.3af PoE with a 15.4 W power budget to power devices like phones or cameras.
Q: What storage and UniFi application support does the UDR7 offer?
A: The UDR7 comes with a 64 GB microSD card pre‑installed for UniFi Protect NVR usage, with the option to upgrade. It runs the full UniFi OS, hosting apps like Network, Protect, Access, Talk, and Connect.
Q: What security, VPN, and SD‑WAN features are built into the UDR7?
A: It provides a stateful firewall, Layer 7 application filtering, IDS/IPS up to ~2.3 Gbps throughput, content/ad filtering, and license‑free SD‑WAN including IPsec, WireGuard, OpenVPN, Teleport, Identity VPN and Multi‑WAN load balancing.
